MARANTZ M1 + BOWERS & WILKINS 603S3B BUNDLE BLACK
Kit Comprises:
- 1 x Marantz Model M1 Wireless Streaming Amplifier (01458215)
- 1 x Bowers & Wilkins 603 S3 3-Way Floorstanding Speakers (39817762)
Marantz MODEL M1 Wireless Streaming Amplifier
The MODEL M1 is engineered with performance and versatility in mind. Enjoy your favourite music, movies or TV shows with seamless connectivity from one elegant, convenient, compact device. Featuring 100W per channel @ 8Ω (Ohms) in a compact chassis with a modern, stylish look.
Key Features:
- 100W 100W (8ohms, 20 Hz to 20 kHz, T.H.D. 0,05%)
- Supports HEOS, AirPlay2, Bluetooth, Spotify Connect, and more
- 192/24 High-Resolution music support
- Marantz Musical Digital Filtering (MMDF)
- HDMI eARC with Onboard Dolby Digital processing
- 2.4 GHz, 5.6 GHz & 6 GHz wireless plus Gigabit ethernet
- Subwoofer output with full adjustment functionality
- USB Mass storage playback
- Made in Japan

EISA COMPACT STREAMING AMPLIFIER 2024-2025
603S3 3-WAY FLOORSTANDING SPEAKERS - B&W
The 603 S3 is the largest loudspeaker in the 600 Series and is ideal for larger rooms and home theaters. It combines our new Titanium Dome™ tweeter with the accuracy and transparency of our acclaimed Continuum™ cone FST™ midrange driver.
Features:
A celebration of sound
- Room-filling scale and authority come courtesy of two bass drivers, while improved terminals and enhanced drive unit positioning make 603 S3 the most sophisticated affordable tower speaker we've ever made.
Layered, beautiful details
- The new 603 S3 introduces our all-new Titanium Dome tweeter, which combines exceptional resolution and insight with smooth, refined high-frequency reproduction.
- The result? An accurate and immersive insight into your favorite music.
Truly amazing sound
- 603 S3 introduces our new and even more acoustically transparent tweeter grille mesh, first developed for our revered Signature models.
- Alongside the new Titanium Dome tweeter, the resolution and realism is exceptional.
Precision and transparency
- Thanks to its composite construction, the Continuum cone avoids the abrupt transitions in behavior that can impair the performance of a conventional drive unit.
- With 603 S3, experience a more open, neutral performance that delivers voices and instruments with precision and transparency.
Upgraded speaker terminals
- Derived from the speaker terminals recently introduced in our 700 Series range, the speaker terminals on the new 603 S3 feature an improved layout and a cleaner signal path between your amplifier and your loudspeakers.
{tab Features}
Marantz MODEL M1 Wireless Streaming Amplifier
The Power To Impress
The MODEL M1 is suitable for a wide range of speakers, from bookshelf to floor standing, and in-ceiling or wall-mounted speakers. Its high-power amplification is highly efficient and offers 100W of stereo output with phenomenally low distortion measured at just 0.005% THD via its digital inputs, a figure typically found in amplifiers costing a great deal more. There's also the option to add a subwoofer for a 2.1-channel experience, and the MODEL M1's advanced configuration options allow for full adjustment of both high-pass and low-pass-filter frequencies independently, along with /-15dB of subwoofer level trim.

True Marantz Power
MODEL M1’s 100W per channel of high-quality, low-distortion amplification delivers pristine sound anywhere, while a subwoofer output delivers room-filling scale in larger spaces.

High Resolution Digital Direct
However you choose to stream your high-resolution music, MODEL M1 has you covered, with support for HEOS, AirPlay2, Bluetooth, Spotify Connect, and more.

Marantz Multi-Room
The expansive feature set yet diminutive size of M1 makes it the ideal partner for multi-room listening.

Marantz Musical Digital Filtering
MMDF is a unique and sophisticated digital filtering technology that reveals the natural detail and tonality in sound.

TV Sound: Marantz Quality, Soundbar Simplicity
Unveil superb sound from movies and TV programs with MODEL M1 using HDMI eARC and onboard Dolby Digital processing.

Welcome To The Digital Domain
The MODEL M1's powerful amplification is complemented by full high-resolution music support. The MODEL M1 supports the full high-resolution music experience over streamed services, your network or even USB, including 24-bit/192kHz PCM support as well as DSD. To ensure these high-resolution signals are delivered in the best possible quality, MODEL M1 operates in the digital domain from end to end. This simplifies the signal flow and eliminates errors caused by the inexpensive DACs typically found in traditional hi-fi. It also means all sources leverage the powerful DSP technologies built in, including Marantz Music Digital Filtering (MMDF), first developed for the brand’s reference-grade audiophile CD players and designed to ensure the characteristic warmth and musicality of any Marantz product.

HEOS Built-in
With HEOS® Built-in technology, use the HEOS app to access all the music services available on the HEOS platform. Also with other connected HEO enabled devices you can enjoy your favourite music in any room of your home for a wireless, whole-home audio experience. Play the same song in every room or select a different song for each connected room - the choice is yours.
In addition to HEOS, MODEL M1 supports Bluetooth, Spotify Connect and AirPlay2 (as well as soon-to-be-released updates for TIDAL and Roon Ready support!), ensuring wide- ranging wireless music streaming for almost any content you may wish to access, and from almost any device. You can even play audio from a locally connected USB-A drive, making this compact product a powerhouse of connected, streamed and network-served high-resolution audio.

The Heartbeat Of Your Home
When you’re not listening to music, the MODEL M1 is a perfect alternative to a soundbar or to an AV receiver for high-quality TV watching. Its included eARC HDMI input means simple one-remote control over system volume levels and power management using your TV’s supplied handset.
The onboard Dolby Digital decoding supports a range of useful adjustment functions for an optimised experience whatever and whenever you are watching. That includes a Dialogue Enhancer option to make voices more easily discernible when listening at low volume levels, plus a Virtual mode that utilises Dolby processing to generate a large, three-dimensional sound field from stereo-only content - perfect for homes where a larger full-sized surround sound system simply isn’t an option.
{tab Specifications}
Marantz MODEL M1 Wireless Streaming Amplifier
Amplifier
Power Amplifier Rated output & THD (8 ohm): 100W 100W (8Ω/ohms, 20 Hz to 20 kHz, T.H.D. 0,05%)
Power Amplifier Rated output & THD (4ohm): 125 W 125 W (4Ω/ohms, 1 kHz, T.H.D. 0.05%)
Frequency Response: 20 Hz to 20 kHz : ±1 dB
Connected loudspeaker Impedance Audio Inputs / Outputs: 4 – 16 Ω/ohms
Audio Inputs / Outputs
Loudspeaker Binding Posts: 4-way binding posts
Digital Inputs: HDMI (eARC), TOSLINK
Analogue Inputs: RCA L/R
Subwoofer Out: RCA Mono
Audio Options
Channel Assignments: Stereo (Default), Dual Mono
Volume Limit: 80-100%
Balance: -15dB to 15dB
Adjustable High Pass / Low Pass Filters: 40-250 Hz / 40-120 Hz
EQ: Bass, Treble -5dB to 5dB
Sound Modes: Stereo, Direct, Virtual, Dialog Enhancer, Night Mode
TV Sound Grouping: Yes
Audio Format Support
Decoding: Dolby Digital , Dolby Digital, LPCM, DSD
Stereo PCM / Multi-channel PCM: Yes / Yes
Stereo File Formats (HEOS network share or USB): WMA: up to and including 192 kbps, AAC & MP3: up to and including 320 kbps, WAV, ALAC, FLAC: up to and including 24-bit/192kHz, DSD: 2.8 MHz, 5.6MHz
Streaming Technologies
Bluetooth Receive: BT 5.X
Bluetooth Transmit: No
AirPlay: AirPlay 2
Spotify: Spotify Connect
Music Services and Sources
Music Services Supported (HEOS, subject to change and local availability): Spotify, TuneIn, Amazon Music, Tidal, Tidal HiRes, Deezer, Deezer HiFi, Mood:Mix, Sony Hi- Res, SoundCloud
Music stored on mobile device: Yes (iOS, Android or Kindle Fire)
NAS (Network Attached Storage): Network share, DLNA
USB Storage Device Playback: Yes (FAT32, NTFS formatted drives)
Networking & Control
Wired Connectivity: Ethernet
Wireless Connectivity: Dual band, 802.11 a/b/g/n/ac
IR Input: 3.5mm
IR Learning: Yes
Control System Compatibility via TCP/IP: Crestron, Control4, AMX
HEOS App: iOS, Android
General
Available Colours: Black
User Interface: Volume up/down, Play / Pause, Multi coloured LED status indicator, Connect button (rear), Bluetooth button (rear)
Dimensions (W x D x H): 217mm x 239mm x 84mm
Weight: 2.2 kg
603S3 3-WAY FLOORSTANDING SPEAKERS - B&W
Size & weight
Dimensions | Height: 985 mm (38.8 in) cabinet only 1,020 mm (40.2 in) including plinth Width: 190 mm (7.5 in) cabinet only 260 mm (10.2 in) including plinth Depth: 340 mm (13.4 in) cabinet only 368 mm (14.5 in) including grille and terminals 402 mm (15.8 in) including plinth |
Net weight | 27.5kg (60.6 lb) |
Technical details
Technical features | Decoupled Double Dome Titanium tweeter Continuum™ cone FST™ midrange Paper bass cones Flowport™ |
Description | 3-way vented-box system |
Drive units | 1x Ø25mm (1 in) Titanium Dome high-frequency 1x Ø150mm (6 in) Continuum cone FST midrange 2x Ø165mm (6.5 in) Paper bass cone |
Frequency range | -6dB 29Hz - 33kHz |
Frequency response ( /-3dB from reference axis) | 46Hz - 28kHz ±3dB |
Sensitivity (on axis at 2.83Vrms at 1m) | 90dB |
Harmonic distortion | 2nd and 3rd harmonics (90dB, 1m on axis) <1% 100Hz - 22kHz <0.5% 350Hz - 12kHz
|
Nominal impedance | 8Ω (minimum 3.0Ω) |
Recommended amplifier power | 30W - 200W into 8Ω on unclipped programme |
Max recommended cable impedance | 0.1? |
Finishes
Cabinet finishes | Black White Oak |
Grille finishes | Black (Black) Grey (White and Oak) |
