| CAMERA | Image Sensor | 1/3″ Progressive Scan CMOS |
|---|
| Max. Resolution | 2560 × 1440 |
| Min. Illumination | - B/W: 0.01 Lux @ (F1.6, AGC ON)
- B/W: 0 Lux with IR
|
| Shutter Time | 1/3s to 1/100,000s |
| Day & Night | IR cut filter |
| Solar Panel Angle Adjustment | - Tilt: −45° to 45°
- Rotate: −30° to 30°
|
| LENS | Lens Type | Fixed focal lens, 4mm and 6mm optional |
|---|
| Iris Type | Fixed |
| Aperture | |
| Depth Of Field | 4mm: 2.7m to 8m |
| FOCAL LENGTH & FOV | Horizontal FOV | 79°, 4mm |
|---|
| Vertical FOV | 43° |
| Diagonal FOV | 93° |
| Lens Mount | M12 |
| IMAGE | SNR | ≥52dB |
|---|
| Wide Dynamic Range (WDR) | Digital WDR |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| POWER | Typical Power Scenarios | 1.85W (4G working) |
|---|
| Standby Scenarios | 80mW |
| Max. Power Consumption | 7W |
| Power Supply | 12V DC |
| For Debugging Only | 6.5W (Deviation: ±1W) Solar Panels |
| Power Interface | - Power Supply Interface: Ø5.5mm coaxial power plug
- Extended Solar Panel: Ø5.5mm coaxial power plug
|
| GENERAL | Material | Plastic |
|---|
| Languages | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Functions | Heartbeat, mirror, flash log |
| ENVIRONMENT | Storage Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
|---|
| Storage Humidity | 95% or less (non-condensing) |
| Startup And Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
| Startup And Operating Humidity | 95% or less (non-condensing) |
| PACKAGING | Dimensions | 213.7mm × 292.4mm × 188.7mm (8.4″ × 11.5″ × 7.3″) |
|---|
| Package Dimensions | 345mm × 240mm × 292mm (13.6″ × 9.4″ × 11.5″) |
| Weight | - Approx. 1.42kg (3.1lb.)
- With Package Weight Approx. 2.07kg (4.6lb.)
|
