| CAMERA | Image Sensor | 1/2.9″ Progressive Scan CMOS |
| Shutter Speed | 1/3s to 1/10000s |
| Slow Shutter | |
| Minimum Illumination | 0.005 Lux; 0 Lux with IR Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/Scheduled/Auto |
| LENS | Type | Motorised Varifocal Lens |
| Focal Length | 2.7mm to 13.5mm (5× Optical Zoom) |
| Aperture | F1.6 |
| FOV | 2.7mm to 13.5mm:- Horizontal FOV: 29.6° to 102.0°
- Vertical FOV: 16.8° to 53.8°
- Diagonal FOV: 34.1° to 122.8°
|
| Lens Mount | Φ14 |
| DORI Distance | 2.7mm to 13.5mm:- Detect: 203ft to 656ft (62m to 200m)
- Observe: 89ft to 276ft (27m to 84m)
- Recognise: 43ft to 131ft (13m to 40m)
- Identify: 23ft to 69ft (7m to 21m)
|
| Angle Adjustment Range (Manual) | - Pan: 0° to 350°
- Tilt: 0° to 75°
- Rotate: 0° to 344°
|
| ILLUMINATOR | IR LED | - Quantity: 4
- Range: 197ft (60m)*¹
- Wavelength: 850nm
|
| Illuminator On/Off Control | Auto/Scheduled/Always On/Always Off |
| VIDEO | Max. Resolution | 2688×1520 |
| Main Stream | Frame Rate:- 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:- 2688×1520, 2560×1440, 2304×1296, 2048×1280, 1920×1080
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Sub-Stream | Frame Rate:- 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:- 1280×720, 848×480, 704×576, 640×480, 640×360, 352×288, 320×240
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Bit Rate Control | CBR, VBR |
| Video Compression | - Main Stream: H.265+/H.265/H.264+/H.264
- Sub-Stream: H.265/H.264
|
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | - Main Stream: 256 Kbps to 6 Mbps
- Sub-Stream: 64 Kbps to 1024 Kbps
|
| IMAGE | Image Settings | - Mirror
- Brightness
- Contrast
- Saturation
- Sharpness
- Exposure
- WDR
- White Balance
- Prevent Over-Exposure to Infrared Light
- HLC Adjustable by Client Software
|
| Image Enhancement | |
| Wide Dynamic Range | 120 dB |
| SNR | ≥52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | |
| AUDIO | Audio Communication | Two-Way Audio |
| Audio Input | |
| Audio Output | |
| Audio Compression | |
| Audio Sampling Rate | 8 KHz |
| Environment Noise Filtering | |
| Audio Bit Rate | 64 Kbps (G.711 alaw) |
| NETWORK | Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| ONVIF | |
| API | Open Network Video Interface (Profile S/T/G) |
| Simultaneous Live View | - 3 × Main Streams
- 3 × Sub-Streams
|
| Client | - VIGI App
- Web UI
- VIGI VMS
- VIGI Cloud VMS
|
| Web Browser | - Google Chrome® 57 and above
- Firefox® 52 and above
- Safari® 11 and above
- Microsoft® Edge 91 and above
|
| Cloud | |
| Security | - Password Protection
- HTTPS Encryption
- IP Address Filter
- Digest Authentication
|
| ALARM AND EVENT MANAGEMENT | Smart Event | - Intrusion Detection
- Line-Crossing Detection
- Region Entering Detection
- Region Exiting Detection
- Object Abandoned Detection
- Object Removal Detection
- Loitering Detection
- People Detection
- Vehicle Detection
- Abnormal Sound Detection
- Scene Change Detection
|
| Basic Event | - Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
- Video Tampering Detection
- Exception (Illegal Login)
- Alarm Input Device
|
| Alarm Linkage | - Memory Card Video Recording
- Push Notifications
- Active Defence-Sound Alarm
- Email Alarm
- Upload to FTP Server
- Alarm Output Device
- Send to Alarm Server
|
| INTERFACES | Network Interface | 1 × RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm | - 1 × Alarm In
- 1 × Alarm Out
|
| Reset Button | |
| Power | DC Power Port |
| On-Board Storage | Built-In Memory Card Slot, supports microSD Card up to 512 GB*³. |
| Built-in Microphone | Yes; Records anything going on within a 16.4ft (5m) radius of the camera. |
| Built-in Speaker | N/A |
| Audio | - 1 × Audio In
- 1 × Audio Out
|
| ENVIRONMENT | Operating Temperature | −30°C to 60 °C |
| Storage Temperature | −40°C to 60 °C |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Storage Humidity | 95% or Less (Non-Condensing) |
| GENERAL | Power Supply | - 12V DC ±5%, 10.8W Max., 5.5mm Coaxial Power Plug
- PoE: 802.3af/at, class 0, 12W Max.
|
| Protection | IP67 Weatherproof, IK10 Vandal Proof |
| Material | Metal |
| Dimensions (L×W×H) | Φ129.9mm × 102.5mm (Φ5.1″ × 4.0″) |
| Net Weight | 0.775 Kg |
| Package Contents | - VIGI Network Camera
- Quick Start Guide
- Waterproof Cable Attachments
- Mounting Accessories
|
| Certifications | CE, NTRA, FCC, VCCI, BSMI, KC, IC, ONVIF, IP67, IK10 |
