CAMERA | Image Sensor | 1/2.9″ Progressive Scan CMOS |
Shutter Speed | 1/3s to 1/10000s |
Slow Shutter | |
Minimum Illumination | 0.005 Lux; 0 Lux with IR Light |
Day/Night Mechanism | IR Cut Filter |
Day/Night Switch | Unified/Scheduled/Auto |
LENS | Type | Motorised Varifocal Lens |
Focal Length | 2.7mm to 13.5mm (5× Optical Zoom) |
Aperture | F1.6 |
FOV | 2.7mm to 13.5mm:- Horizontal FOV: 29.6° to 102.0°
- Vertical FOV: 16.8° to 53.8°
- Diagonal FOV: 34.1° to 122.8°
|
Lens Mount | Φ14 |
DORI Distance | 2.7mm to 13.5mm:- Detect: 203ft to 656ft (62m to 200m)
- Observe: 89ft to 276ft (27m to 84m)
- Recognise: 43ft to 131ft (13m to 40m)
- Identify: 23ft to 69ft (7m to 21m)
|
Angle Adjustment Range (Manual) | - Pan: 0° to 350°
- Tilt: 0° to 75°
- Rotate: 0° to 344°
|
ILLUMINATOR | IR LED | - Quantity: 4
- Range: 197ft (60m)*¹
- Wavelength: 850nm
|
Illuminator On/Off Control | Auto/Scheduled/Always On/Always Off |
VIDEO | Max. Resolution | 2688×1520 |
Main Stream | Frame Rate:- 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:- 2688×1520, 2560×1440, 2304×1296, 2048×1280, 1920×1080
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Sub-Stream | Frame Rate:- 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
- 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:- 1280×720, 848×480, 704×576, 640×480, 640×360, 352×288, 320×240
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Bit Rate Control | CBR, VBR |
Video Compression | - Main Stream: H.265+/H.265/H.264+/H.264
- Sub-Stream: H.265/H.264
|
H.264 Type | High Profile |
H.264+ | Main Stream Supported |
H.265 Type | Main Profile |
H.265+ | Main Stream Supported |
Video Bit Rate | - Main Stream: 256 Kbps to 6 Mbps
- Sub-Stream: 64 Kbps to 1024 Kbps
|
IMAGE | Image Settings | - Mirror
- Brightness
- Contrast
- Saturation
- Sharpness
- Exposure
- WDR
- White Balance
- Prevent Over-Exposure to Infrared Light
- HLC Adjustable by Client Software
|
Image Enhancement | |
Wide Dynamic Range | 120 dB |
SNR | ≥52 dB |
Image Parameters Switch | Yes |
Privacy Mask | Up to 4 Masks |
ROI | 1 Region |
OSD Setting | |
AUDIO | Audio Communication | Two-Way Audio |
Audio Input | |
Audio Output | |
Audio Compression | |
Audio Sampling Rate | 8 KHz |
Environment Noise Filtering | |
Audio Bit Rate | 64 Kbps (G.711 alaw) |
NETWORK | Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
ONVIF | |
API | Open Network Video Interface (Profile S/T/G) |
Simultaneous Live View | - 3 × Main Streams
- 3 × Sub-Streams
|
Client | - VIGI App
- Web UI
- VIGI VMS
- VIGI Cloud VMS
|
Web Browser | - Google Chrome® 57 and above
- Firefox® 52 and above
- Safari® 11 and above
- Microsoft® Edge 91 and above
|
Cloud | |
Security | - Password Protection
- HTTPS Encryption
- IP Address Filter
- Digest Authentication
|
ALARM AND EVENT MANAGEMENT | Smart Event | - Intrusion Detection
- Line-Crossing Detection
- Region Entering Detection
- Region Exiting Detection
- Object Abandoned Detection
- Object Removal Detection
- Loitering Detection
- People Detection
- Vehicle Detection
- Abnormal Sound Detection
- Scene Change Detection
|
Basic Event | - Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
- Video Tampering Detection
- Exception (Illegal Login)
- Alarm Input Device
|
Alarm Linkage | - Memory Card Video Recording
- Push Notifications
- Active Defence-Sound Alarm
- Email Alarm
- Upload to FTP Server
- Alarm Output Device
- Send to Alarm Server
|
INTERFACES | Network Interface | 1 × RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
Alarm | - 1 × Alarm In
- 1 × Alarm Out
|
Reset Button | |
Power | DC Power Port |
On-Board Storage | Built-In Memory Card Slot, supports microSD Card up to 512 GB*³. |
Built-in Microphone | Yes; Records anything going on within a 16.4ft (5m) radius of the camera. |
Built-in Speaker | N/A |
Audio | - 1 × Audio In
- 1 × Audio Out
|
ENVIRONMENT | Operating Temperature | −30°C to 60 °C |
Storage Temperature | −40°C to 60 °C |
Operating Humidity | 95% or Less (Non-Condensing) |
Storage Humidity | 95% or Less (Non-Condensing) |
GENERAL | Power Supply | - 12V DC ±5%, 10.8W Max., 5.5mm Coaxial Power Plug
- PoE: 802.3af/at, class 0, 12W Max.
|
Protection | IP67 Weatherproof, IK10 Vandal Proof |
Material | Metal |
Dimensions (L×W×H) | Φ129.9mm × 102.5mm (Φ5.1″ × 4.0″) |
Net Weight | 0.775 Kg |
Package Contents | - VIGI Network Camera
- Quick Start Guide
- Waterproof Cable Attachments
- Mounting Accessories
|
Certifications | CE, NTRA, FCC, VCCI, BSMI, KC, IC, ONVIF, IP67, IK10 |
