OM4 Laser-Optimized Multimode Fiber (LOMMF) "Aqua" cables, is used for 10/100Gb Ethernet applications. These new technology, 50/125um, LC/LC OM4 Fiber Optic Patch Cord, provide nearly three times the bandwidth over conventional 62.5um multimode fiber, with performance rivaling that of Singlemode cable, at a much reduced cost. LOMMF cable allows 10/100Gb serial transmission over extended distances in the 850nm wavelength window, where low-cost Vertical Cavity Surface Emitting Lasers (VCSELs) enable a cost-effective, high-bandwidth solution. LOMMF is ideally suited for LAN's, SAN's, and high-speed parallel interconnects for head-ends, central offices, and data centers.
Type
Multi-mode 50/125 OM4
Insertionloss
≤0.3dB
Return Loss
≥35 dB
Network Speed
10Gbps / 40Gbps / 100Gbps
Repeatability
≤0.1dB
Durability
≥1000matings
OperatingTemperature
-40°Cto 80°C
Tensile Strength(N)
≥90N(Φ3), ≥70N(Φ2)
