IXWMA IP RELAY 4 X IP - 10 X O/P

AIPHONE

Code: 21817602

1.05 kg
4968249651864
EACH
10
2 IN
STOCK
DON'T PAY $752
TRADE ALERT!
$660 inc GST
Increase value Decrease value
Qty Each (inc GST) Each
Request Price Match
Enter 4 digit postcode

Aiphone - IXW-MA IP RELAY, 4 INPUTS, 10 OUTPUTS

The IXW-MA is a multi-purpose adaptor for the IX Serieswith 4 contact inputs and 10 relay outputs.

The inputs on the IXW-MA can be used to send a command to a specific station to perform a task.

The IXW-MA relays are associated to a specific station and programmed to change state when relay output 1 or 2 on the associated station changes state.

The IXW-MA is a PoE device, and can be programmed via IX Series Support Tool 5.0 or later.



FEATURES

  • New features available for North America with a firmware update
  • Program using the IX Series 2 Support tool
  • Powered over POE, no additional power supply required!
  • Allows connection of theIX Mobile appto an IX Series system
  • 4 activation inputs, 10 relay outputs
  • Line Supervision events from IX Series master can trigger a relay closure
  • Activate with either relay output from IX series stations

Specifications

Power Source: 802.3af PoE compliant

Power Draw: Standby: 43 mA; Maximum: 135 mA

Relay Output: Relays 1-4: Form C 24V AC/DC 500mA - Relays 5-10: Form A 24V AC/DC 500mA

LAN: Ethernet (10BASE-T, 100BASE-TX)

Protocols: IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS

Encryption system: TLS1.0, TLS1.1, TLS1.2

Port Security: IEEE 802.1X

Operating Temp: 14° ~ 104°F (-10° ~ 50°C)

Dimensions: 7-1/2" x 9-5/8" x 13/16"

Weight: 1.39 lbs
