HS4120P 4X 120W POWER AMPLIFIER

HS4120P Australian Monitor 4X120w Power Amp with Dsp & RS232

The HSP series is Australian Monitor's next generation ofcontrollable Class D power amplifiers, delivering high quality audio reinforcement with the power you need in the following options -Single channel 120W or 250W, Dual channel120W or 250W and Quad channel 120W or 250W.

Their new power amplifiers are fully featured, including an efficient Class D amplifier, USB and RS232 control and a mini DSP featuring volume control, mute, compressor/limiter,filter and input channel selection.

The HSP series power amplifiers give the AV contractor a reliable amplifier for applications that are price sensitiveyet still require high quality commercial sound reinforcement and control.

• 4 x 120W power amplifier
• 4 ohm or 70/100 volt output
• Class D topology
• Programmable via PC UI application
• USB and RS232 control
• Mini DSP - Volumes Controls, Input / output routing, High and low shelf filtering, Compressor / limiter, Filtering, Pink noise / sine wave generator, Mutes, Inversion
• Mute control via contact
• Standby control via contact
• Fault status via contact

Specifications

• Output Power per Channel: 120W
• Frequency Response: 100Hz - 16kHz
• Output Channels: 4
• THD N: < 0.2% (-3dB)
• Output Mode: 4 Ohm-70V-100V
• Signal to Noise Ratio: > 92dB
• Input Voltage: 100-240Vac 50-60Hz
• Input Sensitivity: 1Vrms
• Mounting: 2RU
• Cooling: Fan-assisted
• Warranty: 5 years
• Product Dimensions:
  • (W x D x H) 483mm x 389mm x 89mm Shipping Dimensions
  • (W x D x H) 546mm x 491mm x 197mm
• Net Weight: 14.0 Kg
• Shipping Weight: 15.6 Kg

HSP Series Overview

HSP Series connecting speakers
