CIRA824W 8" 8"- 8 OHM IN CEILING SPEAKER

AUDAC QUICK FIT - FAST CON

Code: 39811410

EACH
Special
Buy-In
$180 inc GST
Increase value Decrease value
Qty Each (inc GST) Each
Request Price Match
Enter 4 digit postcode

AUDAC CIRA824W QUICKFIT™ 2-WAY 8" CEILING SPEAKER WITH TWISTFIX™ GRILL

Designed to offer the best value for money ratio. The CIRA series are coaxial 2-way ceiling speakers featuringexceptional intelligibility and musical performance.

The TwistFix™ borderless grill design offers easy but solid assembly and a completely seamless transition fromgrill to ceiling.

This results in a perfect blend in to its environment.

The QuickFit™ installation system combined with FastCon™ connector offers lifetime stability and greatinstallers convenience.

The CIRA8 features a 8” driver using polypropylene cone material, combined with a 1” Mylar tweeter fittedwith a phase plug for excellent off axis performance.

The selected materials guarantee a low distortion performance with smooth and flat frequency response.

A continuous power handling of 40 Watt (RMS) and maximum power handling of 80 watt is achieved, while fitted with a multi-tapping 100V line transformer with tappings for 24W, 12W, 6W and an 8 Ohm connection.



Key Features

  • TwistFix™ technology
  • Tool-free connection
  • Installer convenience
  • 2-way loudspeaker design
  • Weather durable design
  • Invisible grill design



Max. Power 80 W
RMS Power 40 W
Sensitivity (1W/1m) 89 dB
Speaker type 2-way coaxial
Impedance 8 ? (CIRA824)
16 ? (CIRA840D)
Connectors Multi-tap Fast-con™ connections
Sound Pressure (Max. W/1m) @ 100 V 105 dB
Frequency Response (± 3 dB) 40 Hz - 20 kHz
Range (-10 dB) 33 Hz - 20 kHz
Dispersion Conical 140°
Drivers HF 1”
LF 8”
Line Transformer Tappings 1 24 W - 417 ? (CIRA824)
2 12 W - 833 ? (CIRA824)
3 6 W - 1667 ? (CIRA824)
PRODUCT FEATURES
Cut-out measurement 243 mm (Ø)
Dimensions 270 x 82 mm (Ø x D)
Weight 1.65 kg (CIRA840D)
1.75 kg (CIRA824)
Operating temperature -20 °C ~ 60 °C
Construction ABS
Front finish Twist-Fix™ borderless finely perforated steel grill
Built-in depth 82 mm
Mounting QuickFit™ mounting system
Colours White (RAL9003) (CIRA824/W & CIRA840D/W)
