UE1P 1 PORT USB 2.0 CAT5 EXTENDER

KRYSMA USB 2.0 1-PORT CAT5 EXTENDER KIT 150M

Features

Krysma USB 2.0 CAT5/6 Extender can be used to extend the distance between a USB peripheral device and host computer by up to 150m.

This device is a cost effective and high performance USB 2.0 extender, compliant with USB 2.0 Specifications (up to 480Mbps).

It consists of a local unit which connects to the computer and a remote unit that connects up a USB peripheral. Standard, low cost CAT5/5e/6 network cable (not included) is then used to bridge the connection between the two units.

Specifications

General

• USB 2.0 interface, backwards compatible with USB 1.1/1.0
• Maximum distance between Local and Remote Unit: 150m
• Connection via CAT5 (or higher) cable
• Plug & Play installation, no drivers required
• Compatible with all OS with USB support
• Temperature Range: 0° – 40°C (operating), -10° – 70°C (storage)
• Humidity: max. 80% (operating), max. 95% (storage)

Transmitter

• Ports:RJ45 Female, 1x USB 2.0 Type B Female, 3.5/1.35mm Outer/Inner DC socket
• Dimensions (WxDxH):
• Weight: 87g
• Metal Housing

Receiver

• Ports: RJ45 Female, 1x USB 2.0 Type A Female,3.5/1.35mm Outer/Inner DC socket
• Dimensions (WxDxH):
• Weight: 86g
• Metal Housing

Package Contents

• 1x USB 2.0 1-port CAT5/6 Extender (150m)
• 1x 5V 2A DC Power Adapter
• 1x USB 2.0 Type A/B Cable
• 1x User Manual
