| Power source | 100 - 240 V AC, 50 / 60 Hz |
| Rated output | 240 W |
| Frequency response | 50 Hz - 20 kHz (±3 dB (1/8 rated output) |
| Distortion | ≤ 1 % (at 1 kHz, rated power) |
| Power consumption | 314 W (at rated output), 70W (EN62368-1) |
| Speaker output | direct, zones 1 & 2 |
| Amplifier | Class D |
| S/N ratio | 88 dB (A-weighted) |
| Connectable microphones | 3 |
| Inputs | INPUT 1, 2: –60 dB* (MIC)/–20 dB* (LINE) selectable, 600 Ω, electronically-balanced, removable terminal block (3.81 mm, 5 pins)/Ø6.3 mm phone jack (2P) INPUT 3: –60 dB*, 600 Ω, electronically-balanced, Ø6.3 mm phone jack INPUT 4: –60 dB* (MIC)/–20 dB* (LINE)selectable, 600 Ω, electronically-balanced, Ø6.3 mm phone jack (2P) INPUT 5: –20 dB*, 10 kΩ, unbalanced, RCA pin jack x 2 PWR AMP:IN: 0 dB*, 600 Ω, unbalanced, RCA pin jack |
| Control input | 2 channels, no-voltage make contact input, openvoltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 5 pins); ZONE control: No-voltage make contact input, openvoltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 4 pins) |
| Outputs | REC, LINE 1/1: 0 dBV, 600 ohms, unbalanced, RCApin jack SPEAKER direct, zones 1 and 2: 4-16 ohms in totalor 100 V |
| Control output | Power remote, emergency, zone control: Open collector output, withstand voltage: 30 V DC or less, control current: 25 mA or less, removable terminal block (3.50 mm, 4 pins) |
| Operating humidity | 85%RH or less (no condensation) |
| Operating temperature | –10 to 40 °C |
| Finish | ABS resin, Steel plate, paint, black |
| Dimensions | 420 x 96 x 313 mm (W x H x D) |
| Weight | 4.9 kg |
